Universal LED Dimmer | 0-500W | Trailing Edge Control (RLC)

• 0-500 Watt
• Silent dimming
• 220-240V (AC)
• Phase cut-off and on
• 2 year warranty

Ecodim LED dimmer: Silently dimmable lighting for any interior

With the Ecodim LED dimmer, you can enjoy silent lighting. This dimmer is suitable for both trailing edge and leading edge phase control. This slim and powerful dimmer also offers two-way and two-way switching, making the possibilities virtually endless. You can dim lamps with a range of 0-500 watts (LED 500W and halogen 400W). This allows you to connect a wide range of LED lamps. Ecodim dimmers are known for their user-friendliness and compatibility with virtually all brands of cover material.

Universal compatibility

The Ecodim universal dimmer is designed to work with almost all major brand cover materials, including:
– Berker by Hager
– Busch-Jaeger
– Gira
– JUNG
– Kopp

This means you don't have to worry about the compatibility of the cover material, you can simply choose what best suits your interior.

Advanced functionality and security

The Ecodim dimmer is fully protected against overload, overheating, and interference signals. This guarantees reliable, high-quality operation. You can easily set the minimum and maximum dimming values, so you can always dim your lights to your preference.

Transfer and soft start

The dual L-port allows you to easily connect the dimmer to the live wire. The dimmer is also equipped with a soft-start system, which allows your lights to turn on smoothly without flickering. This ensures smooth and comfortable lighting.

General specifications

Here are some important specifications of the Ecodim LED dimmer:
– Item number: ECO-DIM.03
– Dimmer type: Trailing Edge & Leading Edge / Phase cut-off & leading edge / R, L, C
– Power: 0-500 Watt LED
– Operation: Push/turn
– Input Voltage: 220-240V (AC)
– Hertz: 50/60 Hz
– IP value: IP20
– Material: Aluminum and metal
– Installation depth: 22 mm
– Warranty: 2 years
– Packaging: Individually packed

Not suitable for

This dimmer is not compatible with the following brands:
– Merten 57xx
– D-Life
– Dimmer buttons with click system or clamp mounting such as Busch-Jaeger 6540-7 and Niko XXX-31003

Suitable lamps

The Ecodim LED dimmer is suitable for various types of lamps:
– LED lamps 230V (max. 500W)
– Incandescent light bulbs (max. 400W)
– Halogen lamps 230V (max. 400W)
– Low-voltage lamps with electronic transformer, such as LED lamps with transformer (max. 400W)

Conclusion

With the Ecodim LED dimmer, you get a reliable and versatile solution for all your dimmable lighting needs. The combination of advanced functionality, ease of use, and safety makes this dimmer the ideal choice for any interior. Create the perfect ambiance in your rooms with the Ecodim LED dimmer.
