LED DIMMER MOUNTED MODULE | 0-250W (RLC)

• 0-250 Watt
• Silent dimming
• 230V (AC)
• Phase cut-off and on
• 2 year warranty

LED Dimmer Built-in Module 0-250 Watt – Compact and Universal Dimmer for Optimal Light Management

With the 0-250 Watt LED dimmer module, you can easily create the perfect lighting for your home or office. With a mounting depth of just 15 mm, this dimmer fits seamlessly into virtually any standard flush-mounted box, allowing it to be neatly concealed in walls or ceilings. The module supports both leading-edge and trailing-edge dimming techniques, making it suitable for all types of dimmable lamps without worrying about compatibility.

Flexible Power Capacity and Broad Compatibility

The built-in dimmer supports 0-250 watts of power for LED lamps and up to 300 watts for incandescent or halogen lighting, making it suitable for a wide range of applications. The input voltage is 230V (AC) and the dimmer operates on 50/60 Hz, allowing you to easily use it in various lighting setups.

Suitable lamps for this dimmer include:
– LED lamps 230V (up to 250W)
– Incandescent light bulbs (up to 300W)
– Halogen lamps 230V (up to 300W)
– Low-voltage lamps with electronic transformer/RC (up to 300W)

Robust Protection and Reliability

The LED dimming module is designed to operate safely and reliably under various conditions. It features protection against overload and interference signals, and thanks to a voltage-dependent resistor (VDR), external voltage fluctuations are effectively attenuated. This provides additional protection against fluctuations in light output and prevents flickering, overheating, and damage to your lighting.

Compact Design and Easy Installation

Measuring just 45x45x15 mm, this dimmer fits easily into any standard flush-mounted box, even in low ceilings or compact spaces. This makes it ideal for applications such as LED panels, downlights, and other modern lighting elements. The connected lighting can also be controlled remotely using a Wi-Fi system, eliminating the need for additional switches and allowing you to flexibly adjust the light to your liking.

Precise light control with MIN and MAX settings

For optimal light output, this dimmer offers precise adjustment options:
– MIN adjustment: Regulates the lowest light level for a stable lighting image without flickering.
– MAX Adjustment: Sets the maximum light intensity to meet your brightness needs.

Specifications and Additional Information

– Wattage: 0-250 Watt LED, 0-150 Watt RL
– Voltage: 230V AC, suitable for 50/60 Hz
– Installation depth: 15 mm
– Protection value: IP20
– Warranty: 2 years
– Material: Plastic
– Operation: Push button for easy control

CE certified for Safety and Quality

This dimmer is CE certified, which guarantees reliable performance and compliance with applicable European electrical safety standards.

Summary: Perfect Dimming Solution for Any Lighting System

The 0-250 Watt LED dimmer module is the ideal choice for anyone looking for a versatile, compact, and easy-to-install dimmer that works with both leading and trailing edge phase control. This LED dimmer provides the optimal light level in any room, with reliable interference protection and a sleek design that blends seamlessly into your interior.
